FICON ZOOM PLOW

Snow plows for pickups, tractors and UTVs for professionals and tough conditions. Made in Finland.

FC SNOWPLOWS

Ficon Oy is known for it’s excellent quality and customer satisfaction. We are an expert in the field of real estate management and road maintenance equipment, and our products are designed for professional use as well as for heavy loads. With the quick mount, the plow can be attached or detached from the car in as little as a minute.

FC 15-25 ZOOM PLOW

The FC 15-25 ZOOM PLOW is a groundbreaking new product from Ficon that includes unique solutions to ensure durability. The 6 mm thick steel frame and wing parts make the blade strong and impact-resistant, even in more demanding use. The over-rotation stops, equipped with rubber cushions, protect the turn cylinder, and the double spring trigger mechanism allows the blade to fold back when driving into low obstacles.

Usability is further enhanced by the hydraulic end flaps, which conveniently lift backwards, allowing them to be used in tight spaces. The pressure relief valves allow the end wings to slide backwards if they hit an obstacle or the ground, preventing damage.

The blade frame features an integrated 3-point hitch and a bolt frame for tool attachments, making it easy and quick to swap attachments according to the machine being used. The blade is fastened with a standard bolt pattern.







STANDARD FEATURES

  • Double spring release mechanism
  • Floating mechanism
  • 7-pin socket
  • 2 pressure line system
  • Over-rotation stops with rubber cushions
  • Bolt frame for tool attachment
  • Hydraulically operated end flaps, with safety valves

Plow operation needs 3 electric commands

  • Widening simultaneously
  • Right end flap up/down
  • Left end flap up/down
    By request end flaps can be operated simultaneously, when only 2 electric commands is needed.

OPTIONAL FEATURES

  • LED-position lights
  • 4 pressure line hydraulic system (0-1 electric command + 4 pressure connections)
  • Plow shoes
  • Pressure hoses between plow and machine with connectors
  • Connection cable 7-pin, flexible
  • Machine-specific attachments



FC ZOOM PLOW AVAILABLE IN THREE SIZES

  • 13-23 ZOOM, 450 kg
  • 15-25 ZOOM, 580 kg
  • 18-29 ZOOM, 630 kg
